VERITAS NetBackup 5240 Hardware Installation Guide

Riser 2
Riser 3
Lifting frame
Gold pins
SAS RAID card slot
SAS RAID card screw
7
Remove the screw in slot 1 of riser 2.
8
Align the connector on the PCIe card with the bottom socket (Slot 1) on riser
2. The edge connector is designed to install one way only.
81Adding one or more storage shelves to an operating 4TB appliance that does not have any storage shelves
Installing the External Storage Kit components
