Vertiv™ | Liebert® AHU | User Manual 31
Table 3-1 Main Display Controls and Options
No. Description
1 Alarms present: Displays the number of active alarms
2
Menu icon: When unlocked, displays a menu for user or service option depending on which icon is
selected
3
User icon: When selected the user options are available on the main display and menu
(Note: Unlock the display with the user Password to access the menu and options. See “Powering-On
iCOM and Logging-in/Unlocking Controls”)
4
Service icon: When selected the service options are available on the main display and menu
(Note: Unlock the display with the user Password to access the menu and options. See “Powering-On
iCOM and Logging-in/Unlocking Controls”)
5
Advanced icon: When selected the advanced options are available on the main display and menu
(NOTE: Unlock the display with the Service Password to access the menu and read-only options. See
“Powering-On iCOM and Logging-in/Unlocking Controls”
6
Cooling-unit parameters: Status display of selected system parameter settings. See Adding and
Adjusting Content
7 Unit Identification: You can customize the unit name up to 6 characters/ numbers
8 Search icon: Open the keyboard to search for controls and setting locations. See “Searching”
9 Date/ Time
10
Lock/Unlock icon: Indicates whether or not the user and service is logged-in and options are
accessible
Locked icon = display is read-only
Unlocked icon = User or service is logged-in and option is accessible
See Powering-on iCOM and logging-in/Unlocking Controls
11
Secondary-content panel: When accessing setting/configuration via the menus, the settings are
displayed in the right, ‘Secondary’ panel
12
Summary of current unit function. You can customize to show fan speed, cooling, percentages from
any installed device, and any physical (sensor) values
13 Status Dial: Circular display of setpoints and environment conditions of the unit. See Touchscreen
14
Teamwork-mode icon: In a panel with status content the Teamwork Mode icon indicates the mode
selected
15 Control header: Control to access the user and service menus. See Control Header
16 Status Header. Displays the alarm status, unit identification, and the current date and time
