Vertiv Liebert AHU - Advanced Menu

Touchscreen Display38
5. BMS & Teamwork Setup: Opens the BMS & Teamwork Setup menu:
• U2U Setup
• Teamwork/Standby
• BMS Setup
6. Scheduler: Opens the SCHEDULER panel.
7. Options Setup: Opens the OPTIONS SETUP panel.
8. Auxiliary Device Setup: Opens the Auxiliary Device Setup menu:
• Sensors
• Analog Input
• Modbus Devices
• iCOM-DO
• CapCom
9. Backup & Security: Opens the Backup & Security menu:
• Control Upgrade
• Control Backup/ Replicate
• Control Files
• Display Upgrade
• Display Backup/ Replicate
10. Turn Unit On/ O: Depending on unit’s status, open the TURN UNIT ON or TURN UNIT OFF dialog. See Powering-on the
Thermal Management Unit or Powering-o the Thermal Management Unit.
3.3.11. Advanced Menu
The advanced menu provides a read-only view of the advanced set-up and factory-level settings.
Advanced Menu Options:
1. Factory Settings: Unit-code and configuration settings.
2. Diagnostic: Details about control and cooling operation.
3. Expert Settings: Parameters and settings for use by trained professionals only.
4. MBV Settings: Motorized ball valve settings (water-cooled heat rejection).
5. Running Monitoring: Details about component run times.
6. Modbus Devices: Information about connected Modbus devices such as power and flow meters.
7. Control Override: Allows simulating events and override of analog outputs beyond normal limits.
8. Parameter Directory: A searchable list of all parameters in the user interface.
