Vertiv | SmartAisle2 | User Manual 63
Installation
Figure 2-63 The bottom of the door box is connected and fixed
• Disassembled structural parts should be properly preserved to avoid scratches after disassembly.
• Disassembled fasteners are classified according to the structural components to avoid loss or confusion.
• The door box frame and door base connection screws, and the door box frame and the floor screws are not
the same, so utmost care must be taken with this installation point.
Figure 2-64 End door frame mounted state of the cartridge
