8.1.4. Third Row - Hydrogen Flow
This row displays the current quantity of hydrogen being produced. Each point represents about 10 % of
maximum capacity.
This graph also indicates approximately how much hydrogen is being consumed by the connected
equipment.
Note: If only the last point on the ow graph ashes, the generator produces at the
maximum of its capacity. If the consumption is near the maximum limit, the unit may
shut down if consumption increases further. Maximum ow is normal when the unit is
building up pressure.
8.1.5. Fourth Row - Water Quality
This graph shows the quality of the water. With more than 3 points illuminated, water quality is good. If only
3 or less points are illuminated, the conductivity of the water is around 10µS (pre-alarm level). If only 1 or no
point is illuminated, the conductivity of the water is equal to or greater than 15µS (alarm). The generator will
shut down.
8.1.6. Start/Stop-Reset Button
The Start/Stop button places the generator in normal operating mode from “Standby” and vice-versa. It is
also used to re-start the unit after an alarm. When the problem which caused the alarm has been resolved,
the generator must be reset by the “Reset” button, and the generator be started by pressing the “Start/
Stop” button.
8.1.7. Exit-Menu Button
“Exit” returns to previous display.
“Exit” conrms a selected parameter e.g. YES/NO
