NM & PG PLUS FID STATIONS
USER MANUAL
Version 1.03.0000
www.vicidbs.com
CONDITION WARMUP/CHECK
PRESSURE
YELLOW
LED STATUS
READY
GREEN
LED STATUS
CHECK SYSTEM
RED
LED STATUS
Power fault OFF OFF OFF
Heater control fault: catalyst temperature ex-
ceeds maximum allowed 650ºC
OFF OFF ON
Catalyst replacement warning:
At 3 years (generator still operates) Blinking 1Hz
At 3 years, 2 months (generator stopped) OFF ON
Start-up:
QuickStart mode (0 to 3 minutes maximum) Blinking 1Hz OFF OFF
Warm-Up mode (3 to 40 minutes minimum) Blinking 1Hz OFF OFF
System fault: catalyst temperature is low at the
40 min. checkpoint
OFF OFF ON
Operation:
Normal device operation OFF ON OFF
10.2.2. Error Codes on Mainboard
DISPLAY
NUMBER
CHECK SYSTEM
RED LED STATUS
DESCRIPTION
BLINKING 4 BLINKING Catalyst replacement pre-alarm
4 ON Catalyst replacement alarm
5 ON Minimum temperature alarm pre-heating timeout
6 ON Maximum temperature alarm
7 ON EEprom alarm
8 N/A During start-up the code 8 is shown if the bridge is short to reset
the timer for catalyst/oven. Contact your service department.
