NM & PG PLUS FID STATIONS
USER MANUAL
Version 1.03.0000
www.vicidbs.com
4. SPECIFICATIONS
GENERAL
Operating temperature ºC (ºF) 15 to 35 (59 to 95)
Operating relative humidity 0 to 80%, non-condensing
Dimension mm (in) 690W x 150H x 680D (27W x 6H x 26.7D)
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Electrical protection Transient over-voltage until over-voltage category II (Accept transient
over-voltage occurring on the network)
General earth connection is done by the main power supply cable.
Fuse F2 : 5x20mm, 4.0 or 6.3 A T (see “Fuses and Voltage Setting”)
Microprocessor controlled Graphic display - Touch Screen, 128 x 64 pixels
Pollution degree 2
IP protection degree IP20
Atmospheric pressure From 850 to 1150 hPa
External vibrations Inferior to 0.05g / 25Hz
Working instruments position Horizontal ONLY
HYDROGEN COMPONENT
TYPE & PURITY FLOW RATE AT STP CC/MIN POWER CONSUMPTION
Hydrogen ow rate - PG models
Purity +99.9996%
HC free
100, 250 65 to 115 W
Hydrogen ow rate - NM models
Purity +99.99996%
HC free
100, 300, 600, 1000, 1350 90 to 400 W
Max outlet pressure barg (psig) 11 (160)
AIR COMPONENT
TYPE & PURITY FLOW RATE AT STP CC/MIN POWER CONSUMPTION
Zero air purity ow
HC free
1800, 5000 200 to 500 W
Max outlet pressure barg (psig) 5 (72.5) to ±0.1 (±0.5)
STP: Standard temperature and pressure (20°C, 1 barg)
Any changes or modications to this equipment not expressly approved by the manufacturer may void
the user’s authority to operate the equipment.
