VICI DBS NM PLUS - Special Functions and Tests

28
NM & PG PLUS FID STATIONS
USER MANUAL
Version 1.03.0000
www.vicidbs.com
SELECTION DESCRIPTION OPTIONS DEFAULT
Temp. Units Sets the desired unit of measure for the
temperature
ºC or ºF ºC
Volume Units Sets the desired unit of measure for the
volume
scm (standard cubic
meters) scf (standard
cubic feet)
scm
Lock Keyboard If set to YES, the keyboard will be locked au-
tomatically after the generator is in the main
window for more than 20 seconds. To unlock
the keyboard, press the unlock button and
hold for 5 seconds.
YES / NO NO
Set Default Values
**
Sets all conguration parameters to
default
CAUTION:
*The Low Pressure Alarm will never activate if the Low Pressure Error is set to 100%.
** After resetting the default value make sure that the auto rell is set to ON again.
8.4. DIAGNOSTIC DISPLAY
SELECTION DESCRIPTION
Production Tot. Total production of hydrogen
Operating time (h) Total number of hours the unit has been in operation
Wat. Quality (µS) Actual water conductivity
Int. Press. Actual internal pressure of the unit
Cell Voltage (V) Actual cell voltage
Cell Current (A) Actual cell current
PS. Temp. Actual temperature of the power supply
Cell Voltage Peak (V) Maximum cell voltage in the life of the cell
PS. Temp. Peak Maximum temperature of the power supply reached
Pump Flow (L/min) Actual ow of water
(CONTINUED FROM PREVIOUS PAGE)
