Table of contents
3
1.0 General information
1.1 Machine specification 4
1.2 Machine dimensions 5
1.3 Safety symbols 6
1.4 Changing RPM 13
2.0 Attachment
2.1 Stetting of 540 or 1000 rpm for PTO 14
2.2 Attaching the machine to the tractor 15
2.3 Bleeding PTO 18
2.4 First start up of machine 19
2.5 Adjusting ground pressure 20
2.6 Setting stubble height 21
3.0 Maintenance
3.1 Basic instructions 24
3.2 Torques 25
3.3 Maintenance intervals 26
4.0 Components
4.1 PTO's - clutch 27
4.2.1 Lifting cylinders 33
4.2.2 Replacement cylinder(s) 36
4.3 Steering cylinder 38
4.4 Press relieve valve 39
4.5 Hydraulic diagrams with functions 40
4.6 Swivel gearbox incl. repair instructions 43
4.7 Bevel gearbox incl. repair instructions 51
4.8 Cutter bar details 58
4.8.1 Cutter bar repair instructions 65
4.8.2 Cutter bar maintenance 75
4.8.3 Cutter bar; changing oil 78
4.9 Bevel gearbox; changing oil 79
4.9 Swivel gearbox; changing oil 80
4.1 Lubrication 81
4.1 Wheel info incl. torque and hub info 83
5.0 Options 84
6.0 Troubleshooting 88
