Attachment of the tractor
Attachment of the Quick
Coupler.
Attachment of the tractor
Attachment of the Quick
Coupler.
Attachment of the tractor
Attachment of the Quick
Coupler.
Attachment of the tractor
Attachment of the tractor
We have 2 standard versions;
• Quick Coupler; the one shown
on the LH side, is standard on
machines for all countries
except the US.
The Clevis Coupler shown on
the RH side is optional.
• Clevis Coupler is standard on
machines for USA / Canada -
Quick Coupler is optional
• Adjust the right and left lift arm
so they are at the same
height.
• Swing the lower link crossbar
to the side or remove the
lower link crossbar.
• Raise or lower the tractor's lift
arms until the swivel hitch can
be mounted on the tractor's lift
arms.
• Fit the swivel hitch on the
tractor's lift arms.
• Secure the attachment with
the locking pin on both lift
arms.
• Attach the PTO shaft to the
tractor.
• The chain is an option!
2.2 Attachment to tractor
15
