Wheel info Wheel info
Hub info
Hub info
After the first 10 hours;
• Use a suitable torque wrench adjusted to the torque
shown in the table below.
• Place the wrench on the wheel bolts.
• Check all the bolts on the wheels and tighten them to the
torque shown.
• Check the tire pressure and, if necessary, top up the tire to
the pressure shown in the table below.
Position Part nr. Amount Description
4 VG38800820 1 bearing tappered roller VN40119108
11 VNB1604878 1 wheel hub 6 hole complete
18 VNB1953802 1 wheel axle
19 VGBR550 1 hub, wheel, 6 hole
20 VGBR552 1 seal
21 VGBR553 1 cover, wheel
22 VGBR444 6 bolt, wheel
30 VGND2134V 6 Nut, wheel
32 KG01253061 1 Split pin 8x60
34 KG01802500 1 Tapper bearing 30211
4.11 Wheel and wheel-hub info
83
