Preparation
44
 Fit the bracket.
 Fit the bolts on both sides of the transmission.
 Tighten all bolts to a torque of 225 Nm.
 Force the corners of the lock plate back in against all the bolt
heads.
 Fit the PTO shaft.
Important!
 Check the oil level in both the upper and lower swivel gears.
 »Swivel hitch« Page 74
Bolt
Bracket
225 Nm
