Operation
56
Working position
The machine is operated in the following way:
Make sure that there are no persons in the surrounding area.
Fasten all the guards on the machine.
Check that the side guard on the cutting unit is folded out and
correctly positioned.
Position the tractor and the machine in a straight line.
Check that the mechanical safety valve is open.
Carefully connect the tractor's PTO shaft.
Carefully increase the speed of the PTO shaft to 540/1000 RPM.
»RPM on the PTO outlet« Page 40
Use the tractor's machine handle to operate the hydraulic
functions.
If none of the machine's functions are working:
Stop the tractor’s forward drive.
Stop the tractor.
Disconnect the PTO shaft immediately.
If the machine is too noisy or vibrates too much, stop the machine
immediately.
»Troubleshooting« page 119.
Valve
