Hydraulic connection
Stop the tractor and remove the ignition key.
The tractor must be fitted with 2 sets of double acting hydraulic outlets,
which are connected as follows:
When connecting the hydraulic hoses you should check that:
• The hydraulic hoses are connected in pairs to the tractor's
hydraulic pressure and return outlet on the tractor.
Checking that the hydraulic system is correctly connected
Ensure that the hydraulic system is correctly connected.
Otherwise, this can cause injuries, and damage to the machine.
Hydraulic hose for: Function
Drawbar
right
left
Cutting unit
up
down
Cutting unit
Drawbar
