Maintenance
79
Pull out and release the lock for the guard.
Open the machine's front guard.
Turn the cutting discs by hand until the damaged knife is in the
position shown.
Inspect the condition of the knives for wear.
Inspect the bolt for damage or wear.
• If the bolt is damaged or worn, it must be changed.
The minimum diameter of the bolt must not be less than 16 mm.
»Knives« Page 104
Check that the bolt is fully tightened.
If not, tighten the bolt to the torque shown.
Minimum
16 mm
95 Nm +/- 5
