15
1.3.2 Specifications
Item UDR-208
UDR-208E
UDR-216
UDR-216E
Image System NTSC, PAL selectable
Video Channel 8 CH 16 CH
Multi-tasking Quad-plex
Video Output 2 Ch Composite(BNC), 1Ch S-Video, 1 Ch Spot, VGA
Video Compression MPEG-2
Recording Resolution NTSC : 640x240, 320x240
PAL : 640x288, 320x288
Recording Quality 4 Levels (Normal, Enhanced, Fine, Super Fine)
Max Recording Speed 120fps (320*240), 100 fps (30*288), 60 fps (640*240)
50 fps (640*288)
NTSC: 1,2,3,4,5,6,7,8,9,10,15,10,30 Time Laps Recording
Interval (FPS)
PAL : 1,2,3,4,5,6,7,8,9,10,15,20,25
Recording Mode Schedule, Event (sensor, motion detection),manual,
Continuous
Playback Search Date/Time, Event (Alarm, Motion detection)
Playback Speed x1, x2, x4, x8, x16, x32, x64, x128, Field by Field
(Forward/ Backward)
Slow Motion X1/4, x1/2 (Forward only)
Sensor Input 8 (NO/NC Selectable) 16 (NO/NC Selectable)
Alarm Output 1 (NO/NC)
Aux Control In/Out 2/3 (Selectable Function Menu)
Alarm Reset In, Record Start In, Record ON/OFF, Alarm Out,
Error Out, Record Start Out, Disk Full Out, Record Status Out
Audio 1CH, mono
Network 10Base-T (STATIC,DHCP, PPPoE, E-mail, & FTP)
Motion Detection 12* 12, 8 Level Sensitivity
Hard Disk Max Two HDD
Backup Method CD-RW,USB Memory, Network
Watermarking Still image backup
PTZ Control RS-485
System Log Video Loss, Power On/Off, HDD Full, HDD Fail, Menu called,
Reset HDD, Format, Reset SW Upgrade, E-mail Fail, FTP fail
Language Korean, English, Japanese, French, Spanish
S/W upgarde Network, USB Memory stick
Password Function Power ON/OFF, MENU, Record OFF, Key Lock
Digital Zoom x 2
Timer Built-in real time clock
Remote control Optional
Power Source Free Voltage (100 - 240VAC, 50Hz/60Hz, 70W)
Dimension 433(W) x 385(D) x 88(H)
Operating Temperature
5℃ ~ 40℃
Weight 7 Kg (w/o HDD)
Design and specifications are subjected to change without notice.
