46
IMPIANTI CITOFONICI
CON LETTORE DI PROSSIMITA’ (VPROX)
A fianco vengono presentati 2 schemi applicativi con il modulo lettore
di prossimità Art.849… che: insieme alla CPU Art.VROX-20 permette di
aprire la porta o fare altri servizi tramite la lettura di chiavi (Art.955/T) o
carte (Art.955/C) codificate di prossimità.
L’apriporta o gli altri servizi vengono effettuati dalla chiusura di un relè
che può commutare un carico massimo di 5A a 24Vac/dc per un
tempo programmabile da 2 a 10 sec.
L’unità di controllo Art.VPROX-20 permette:
- La memorizzazione di 20 “chiavi” o 20 “carte” di prossimità.
- Il collegamento di 1 o 2 lettori (ingresso e uscita porta) di prossi-
mità Art.849… tramite 5 fili, per una distanza Max di 200mt.
- La programmazione, tramite 2 dip-swtch, del tempo di chiusura
del relè da 2 a 10 secondi.
- La possibilità di collegare un pulsante apriporta addizionale che
abiliterà il relè per il tempo di ingresso/uscita programmato.
Il sistema è protetto contro un eventuale sabotaggio, in quanto l’unità
di controllo (VPROX-20) è lontana rispetto al modulo di lettura chiave
(Art.849) ed il colloquio fra di loro è di tipo seriale.
Le funzioni dell’impianto citofonico rimangono quelle descritte nelle
pagine precedenti.
Per il collaudo e la programmazione del sistema VPROX-.20 consulta-
re le istruzioni in esso allegate.
INTERCOM SYSTEMS WITH PROXIMITY READER (Vprox)
On these pictures are shown two installation diagrams with the proxi-
mity reader module Art.849…that together with CPU Art.VPROX-20
allows to open the door or to do other services by reading proximity
coded tags (Art.955/T) or cards (Art.955/C).
The door opening or the other services are carried out by closing
relays that can commute a maximum loading of 24Vac/dc 5A from 2 to
10 secs.
The control unit Art.VPROX-20 allows:
- to store up to 20 proximity “tags” or 20 proximity “cards”.
- to connect 1 or 2 proximity readers (entry and exit) Art.849…throu-
gh 5 standard wires up to a distance of max 200mt.
- to schedule, through 2 dip-switches, the time of closing of the relay
from 2 to 10 secs.
- to connect an additional door opening button operating the relay
for the programmed entry/exit time.
The system is protected against sabotage since the control unit
(VPROX-20) is remote from the reader head (Art.849) and if un-stored
keys attempt to operate the system the control unit will disable the rea-
der.
The functions of the intercom system are the same as the ones descri-
bed on the previous pages.
To test and program the system VPROX-20 see the enclosed instruc-
tions.
Fig. 1
n= users
n= utenze citofoniche
924 SMART 1
926 SMART 2
n ...
See type and qty at page 7
Per tipo e quantità vedi a pag. 7
852/..-3/..
See type at page 5
Per tipo vedi a pag. 5
837-2/..
1
See type and qty at page 5 and 9
Per tipo e quantità vedi a pag. 5 e 9
843/..-4/..-5/..
Reader module
Modulo lettore
849
1
Power supply
Alimentatore
520
1
cpu
VPROX-20
1
Fig. 2
n= users
n= utenze citofoniche
925
925S
n ...
See type and qty at page 7
Per tipo e quantità vedi a pag. 7
852/..-3/..
See type at page 4
Per tipo vedi a pag. 4
835M-2/..
1
See type and qty at page 5 and 9
Per tipo e quantità vedi a pag. 5 e 9
843/..-4/..-5/..
Reader module
Modulo lettore
849
1
Trasformer
Trasformatore
522 - 322
1
Cpu
VPROX-20
1
Intercom with door opening button
Citofono con pulsante apriporta
Intercom with door opening button plus service button
Citofono con pulsante apriporta e di servizio
Front support
Sostegno portamoduli
Speaker unit with 2 call buttons
Modulo portiere elettrico con 2 pulsanti di chiamata
Extension front panel module
Modulo di chiamata
Intercom for 1+1 system
Citofono per sistemi 1+1
Intercom with privacy of speech and loch opening for 1+1 system
Citofono con segreto per sistema 1+1
Front support
Sostegno portamoduli
Speaker unit module for 1+1 system
Modulo portiere elettrico per sistema 1+1
Extension front panel module
Modulo di chiamata
