No. Components Descriptions
4
Input Signal Switch /
OSD Menu Select
- Touch to switch input signal (Android / HDMI IN /
D-Sub).
- Select function in OSD menu.
5
Arrow Button
(Up / Right)
Use the arrow buttons (Up / Right and Down / Left)
to move through OSD menus. You can highlight a
menu item by touching the arrow buttons. You can
also use the arrow buttons to adjust the values to
each item of OSD menu.
6
Arrow Button
(Down / Left)
7
OSD Menu / Exit Touch this button to launch the OSD conguration
menu and touch again to exit.
8
Power button Touch to power on / lock the smart display.
- Touch about 0.5 seconds to power on the power.
- Lock the smart display when the display is on.
- Recall the unlock display when the smart display
is locked.
- When the display is on, press this button and
hold for about 3 seconds to shut down the smart
display (under Android mode).
9
LED indicator - LED in blue when power on.
- LED turns into amber when smart display be
locked.
