Vigilant MX1-Au - DIM800 Detector Compatibility

Vigilant MX1-Au Operator Manual Document: LT0439
Page 23 October 2018 Issue 1.73
12-6
Brand
Model & Type
Max Qty
External Supply Voltage
at DIM800
Tyco
614P Photoelectric Detector
25
20V – 28.7V
614I Ionisation Chamber Detector
38
20V – 28.7V
614CH combined CO + Heat Detector
32
20V – 28.7V
614T Heat Detector Types A, B, C, and D.
23
20V – 28.7V
601FEx Flame Detector *
4
20V – 28.7V
S231f+ IR Flame Detector (flameproof)
7
21.0 – 28.7V
FV411f IR Flame Detector (flameproof)
3
23.0 – 28.7V
FV412f IR Flame Detector (flameproof)
3
23.0 – 28.7V
FV413f IR Flame Detector (flameproof)
3
23.0 – 28.7V
Minerva
MD614 Heat Detector
40
20.7V - 28.7V
MR614 Photoelectric Smoke Detector
22
20.7V - 28.7V
MR614T HPO Photoelectric Smoke Detector
21
20.7V - 28.7V
MU614 CO Detector
40
20.7V - 28.7V
MF614 Ionisation Chamber Detector
30
20.7V - 28.7V
T614 Heat Type A, B, C, D
23
20.7V - 28.7V
Simplex
4098 – 9603EA Ionisation Detector
24
18.0V - 28.7V
4098 – 9601EA Photoelectric Smoke Detector
24
18.0V - 28.7V
4098 – 9618EA,-9619EA,-9621EA Heat Detectors
24
18.0V - 28.7V
Olsen
P24B Photoelectric Detector
24
20.7V - 24.7V
P29B Photoelectric Detector
20
20.7V - 26.7V
C24B Ionisation Detector
40
20.7V - 26.7V
C29B (Ex) Ionisation Detector
40
20.7V - 26.7V
R23B Flame Detector
20
20.7V - 24.7V
R24B Flame Detector
3
22.7V - 28.7V
P136 Duct Sampling Unit
5
19.0V - 28.7V
T56B Heat Detector (Z56, Z500 bases)
40
18.0V - 28.7V
Cerberus
DO1101 Photoelectric Smoke Detector
16
21.7V - 27.7V
DLO1191 Photoelectric Beam Smoke Detector
1
22.7V - 28.7V
System Sensor
885WP-B Weatherproof Heat Detector
40
20.0V – 28.7V
-
Hard Contact Devices (T54B, B111, etc.)
40
18.0V – 28.7V
Hard contact devices must be rated for at least 30V and currents up to 50mA.
* Although detector is Ex rated, this is a direct connection without an IS barrier
