Vigilant MX1-Au - Chapter 12 Specifications; General Specifications

Document: LT0439 Vigilant MX1-Au Operator Manual
Issue 1.73 23 October 2018 Page 12-1
This Chapter contains specification data for the MX1.
Refer to the page number listed in this table for information on a specific
topic.
Topic
See Page
General Specifications
12-1
MX1 Analogue Loop Compatible Devices
12-3
DDM800 Detector Compatibility
12-4
DIM800 Detector Compatibility
12-6
Compatible Batteries
12-7
Detector Identification
12-7
Equipment Point Descriptions
12-8
Ordering Codes
12-20
Block Diagram
12-21
General Specifications
Cabinet
Construction
1.2mm/1.6mm mild steel, zinc coated, colour Dulux
Titania Ripple 288 1235Z. Baked epoxy powdercoat
finish. 003 key for outer door.
Dimensions 19” rack
8U: 440 x 550 x 210 mm (H x W x D)
15U: 750 x 550 x 210 mm (H x W x D)
Shipping weight
8U: 17 kg approx., excluding batteries.
15U: 24 kg approx., excluding batteries.
Environmental
Temperature/Humidity
Operating Temperature -5
o
C to 45
o
C.
Humidity up to 95% RH (non-condensing)
Cabinet Protection
IP30
Power Supply
Mains Input
230V a.c. (192-253 V a.c.), 50/60Hz, 1.2A rms max
Charger Output
27.3V d.c. at 20
o
C, 5.0A DC continuous, 5.5A current
limit nominal.
Temperature-compensated at -31mV/
o
C
Batteries (Sealed Lead Acid)
8U: 2 x 12V up to 40Ah capacity
15U: 2 x 12V up to 40Ah capacity.
DC Operating Voltage
19.2V – 28.8V
Fused Supplies
Three VBF and one VRZDU terminals and one VNBF
terminal, wire capacity 2.5mm
2
. Each output is fused
at 3A (20 x 5 slow blow cartridge type).
Addressable
Device Loop
Output loop current
Up to 1.0A continuous. Overcurrent cutout at 1.1A
(nominal).
Terminals
AL+, AL-, AR+, AR-. Wire capacity 2.5mm
2
.
Chapter 12
Specifications
Introduction
In this Chapter
General Specifications
