Vigilant MX1-Au Operator Manual Document: LT0439
Page 23 October 2018 Issue 1.73
12-4
Ordering
Code
Device
Type
Description
Max No. Per
Loop
516.300.412
FV412f
Flameproof Triple-Infrared Flame Detector & PAL Camera
125
516.300.413
FV413f
Flameproof Triple-Infrared Flame Detector & NTSC Camera
125
516.800.956
SAB801
Sounder Base Driver with LED Beacon
250
516.800.954
SAM800
Sounder Base Driver
250
545.800.004
LIM800
Short Circuit Loop Isolator Module
250
517.050.018
5BI
Short Circuit Isolator Base
250
517.050.041
4B
Detector Base
250
517.050.042
4B-C
Continuity Base for 850 detectors
250
517.050.043
4B-I
Short Circuit Isolator Base
250
D51MX
D51MX
Duct Sampling Unit (with 4B-C base)
250
The actual maximum number of devices per loop depends on the mixture of types, cable
type and cable length.
All Cerberus/Olsen detectors listed here for use with the DDM800 are compatible with the
Z52B, Z54B, Z54B Mk2, Z56, and Z500 bases. In addition, the T56B heat detector is also
compatible with the Z55B, Z56N, and Z500N bases.
Brand
Model
Type
Maximum No. per Circuit
Standard Voltage Detectors
-
Hard Contact Devices (T54B, B111, etc.)
40
Kidde
Firewire
Linear Heat Detector
5000 metres
Olsen
C24B
Ionisation
40
Olsen
C29B
Ionisation
40
Olsen
P136
Duct Sampling Unit
7
Olsen
P24B
25
Olsen
P29B
20
Olsen
R23B
Flame
19
Olsen
R24B
Flame
12
Olsen
T56B
Heat
40
Protectowire
Protectowire
Linear Heat Detector
2000 metres
SAFE
ThermoCable
Linear Heat Detector
5000 metres
Simplex
4098-9601EA
25
Simplex
4098-9603EA
Ionisation
31
Simplex
4098-9618EA
Heat Type A
31
Simplex
4098-9619EA
Heat Type B
31
Simplex
4098-9621EA
Heat Type D
31
System Sensor
885WP-B
Weatherproof Heat Type B
40
Tyco
601F
1
Flame
5
Tyco
601FEx
1
Flame
5
Tyco
614CH
CO & Heat
35
Tyco
614I
Ionisation Smoke
40
Tyco
614P
Photo Smoke
40
Tyco
614T
Heat Type A, B, C, D
29
Tyco
FV411f
IR Flame Detector
3
Tyco
FV412f
IR Flame Detector
3
1
Not a CSIRO listed combination.
DDM800 Detector Compatibility
