Provides the status of the door input which uses a clean contact
switch to monitor the door open/closed status. Normal (closed) is
S/C to 0V, ActiveInput (open) is O/C.
Provides the status of the "Firmware Write Enable" jumper.
ActiveInput when jumper is fitted, Normal when not fitted.
Provides the status of the "Database Write Enable" jumper.
ActiveInput when jumper is fitted, Normal when not fitted.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Provides the state of the mains power supply to the panel. This
point is placed into Fault when the mains power has failed, and
Normal otherwise.
Indicates battery voltage low level. Point will be in Fault when the
battery voltage drops below the threshold set in the
configuration, and Normal otherwise.
Indicates battery connectivity. The state is Normal if the battery is
found to be connected or Fault if the battery is disconnected or
very discharged.
Indicates earth monitoring fault condition. Point will be in Fault
when an earth fault is detected, Normal otherwise.
Indicates battery test state. Point will be in ActiveInput when
battery test is active, Normal otherwise.
Provides the status of the fuse (F3) protecting the ANC1 power
supply (J4-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
Provides the status of the fuse (F4) protecting the ANC2 power
supply (J5-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
Provides the status of the fuse (F5) protecting the ANC3 power
supply (J6-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
Provides the status of the fuse (F2) protecting the RZDU power
supply (J24-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
Indicates that the long-term battery test has failed. Point will be in
Fault while test is running and has failed, Normal otherwise.
Provides the status of the fuse (F6) protecting the non-battery
backed power supply (J15-1). Normal indicates the fuse is intact,
Fault indicates that the fuse has blown or is not fitted.
Provides indication of whether the charger voltage is higher than
it should be. The threshold is determined by the Charger High
voltage setting in the configuration. Normal indicates the charger
voltage is less than the specified voltage, Fault indicates that the
charger voltage is too high.
Provides indication of whether the charger voltage is lower than it
should be. The threshold is determined by the Charger Low
voltage setting in the configuration. Normal indicates the charger
voltage is higher than the specified voltage, Fault indicates that
the charger voltage is too low.
