Vigilant MX1-Au Operator Manual Document: LT0439
Page 23 October 2018 Issue 1.73
Provides the status of the controller firmware. The point state is
Fault if a CRC check of the firmware fails, otherwise the state is
Normal.
Provides the status of the Controller boards RAM. The point
state is Fault if an error is detected with the RAM, otherwise the
state is Normal.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
This point indicates that there are one or more foreign RZDUs
detected in the system. The point state is Fault if a reply is
received from an RZDU with an address that corresponds to an
RZDU that is not enabled in the configuration data file. The fault
will automatically clear if replies from the foreign RZDU stop
being received.
Provides status of the MX1 Commission Test function, for recall
on the LCD and to light the Tests indicator on the keypad. When
Commission Mode is active, the status of this point will show
ActInput and TestOp. Otherwise it will show Normal.
This point signals Fault for 12 seconds following restart of the
panel. This includes cold starts, user initiated reboots, and
system controlled or uncontrolled watchdog restarts. The Startup
Flags status can be used to ensure that a fault is sent to the
brigade signalling equipment, or not.
This point signals fault if the MX1 has what appears to be an
uncorrupted configuration data file but which contains compiled
Output Logic with fatal problems. If this fault is signalled, the
ability of the MX1 to act as a fire alarm is severely compromised.
The MX1 firmware will force the System Fault and Faults
indicators on, and will force the fault relay into its de-energised
state. This fault can only be corrected by restarting the panel
using a configuration data file with output logic compiled without
the problem, which could be either the alternative configuration
data file stored in the MX1 or a newly downloaded configuration
data file.
This point signals when the AIF is in attended mode.
This point is disabled if the printer output is disabled.
Point is unused but included for future enhancement.
Provides the common status of the routing outputs. The status
will show Alarm when the Alarm routing output should be
activated, ActInput when the Fault or Disables routing outputs
should be activated. It will become disabled when all of the
Alarm, Fault and Disables routing points are disabled. It cannot
be enabled until at least one of those points becomes enabled.
