Vigilant MX1-Au Operator Manual Document: LT0439
Page 23 October 2018 Issue 1.73
Indicates fault if the I-HUB has discarded a message after not
receiving confirmation of reception from the remote device
despite multiple retries. This can be caused by a fault or failure of
the device connected at the remote end, wiring faults,
overloading, or noise. The port number that the fault has occurred
on is indicated in a MX1 system event.
Indicates fault if the I-HUB has had a queue overflow and
message(s) have consequently been lost. This could be due to a
wiring fault, device failure, noise, or other network performance
problems. The port number that the fault has occurred on is
indicated in a MX1 system event.
Has an active status if the I-HUB has had a queue exceed the
configured queue warning level. This could be due to a wiring
fault, or other network performance problems. The port number
that the warning has occurred on is indicated in a system event.
Indicates fault if the I-HUB has a generic fault. This is for use with
future versions of the I-HUB firmware – connect to the I-HUB’s
diagnostic port for more information.
Has an active status if the I-HUB has a generic warning. This is
for use with future versions of the I-HUB firmware – connect to
the I-HUB’s diagnostic port for more information.
Provides status of the MX1 connection to the PIB. Fault indicates
that communication is not possible – usually because the wrong
serial port is used, the connection is broken, the PIB is turned off,
or a non PIB device is connected. This will also indicate fault
when a PIB with V1.02 or below firmware is connected.
Refer to NETWORK CONNECTION STATUS below for
descriptions of the text displayed.
Provides status of remote PIB(s) reported by the local PIB that is
connected directly to the MX1.
Provides the external fault status (usually wired to indicate a ring
break on the IP network) of the local PIB that is connected
directly to the MX1.
PIB - Remote
PIB External
Fault (FAS1)
Provides the external fault status (usually wired to indicate a ring
break on the IP network) of remote PIB(s) reported by the local
PIB that is connected directly to the MX1.
PIB - PIB
Internal / IP
Connection
Indicates fault if the PIB has an internal fault (e.g. checksum
failure), or the Ethernet / IP connection has failed.
Indicates fault if the PIB has detected a PSU fault (voltage below
minimum).
PIB - PIB
PLink
Message
Discard
Indicates fault if the PIB has had to discard message(s) on the
Panel-Link interface. This could be due to a wiring fault.
Indicates fault if the PIB has had a queue overflow. This could be
due to a wiring fault, or other network performance problems.
