Vigilant MX1-Au Operator Manual Document: LT0439
Page 23 October 2018 Issue 1.73
12-16
Point
Point
Description
Description
243.1.10
Access Level 2
This point determines whether the menu will be in Access Level
2. If the operate state is true, menu level 2 access is enabled.
243.1.11
Alarm Buzzer
This point shows the state of the alarm buzzer on the
LCD/keyboard, which is controlled directly by internal logic. It is
also sent to any RDUs allowing the buzzer to be mimicked.
ActInput indicates that the alarm buzzer is active.
243.1.12
Fault Buzzer
This point shows the state of the fault buzzer on the
LCD/keyboard, which is controlled directly by internal logic.
ActInput indicates that the fault buzzer is active. It is also sent to
any RDUs allowing the buzzer to be mimicked.
243.1.13
LCD Fault
This point is placed into fault when the LCD/keyboard LCD fails.
243.1.14
Buzzer Disable
This point indicates as Disabled when the buzzer has been
disabled, and TestOp when the buzzer is muted.
243.2.0
through
to
243.19.0
Switch Input n
This point is placed into ActInput if switch input n on the keypad is
active.
243.20.0
through
to
243.35.0
Open Collector
Output n
This point drives the open collector output n. Its operate state can
be driven by the mapped zone's operate state or by logic.
243.36.0
FRC Monitor
This point is placed into fault when the FRC to the 26 way Switch
Input connector is removed.
243.36.1
Switch Input set 0
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 0, which contains inputs 16-18.
243.36.2
Switch Input set 1
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 1, which contains inputs 1-3.
243.36.3
Switch Input set 2
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 2, which contains inputs 4-6.
243.36.4
Switch Input set 3
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 3, which contains inputs 7-9.
243.36.5
Switch Input set 4
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 4, which contains inputs 10-12.
243.36.6
Switch Input set 5
Monitor
This point is placed into fault when the end-of-line resistor is
missing from switch input set 5, which contains inputs 13-15.
243.37.0
Fire Protection
Active
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
243.37.1
Smoke Control
Active
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
243.37.2
Spare Indicator
When this point is placed into the Operate state by a logic
equation the corresponding indicator on the keypad turns ON.
243.37.3
Spare Indicator A
NOT SUPPORTED
243.37.4
Spare Indicator B
NOT SUPPORTED
Point
Point Desc.
Description
244.x.0
Scan status
This point is in fault if the MX1 does not receive replies from the
RZDU.
244.x.1
Callpoint
This point is in alarm and/or fault if the MCP at the RZDU is in
alarm and/or fault.
244.x.2
Batt Low
This point is in fault if the battery voltage is low at the RZDU.
Equipment 244
– RZDU Points
