Event ID Description
0xE8FB CMD - Auto command: Error: Initialization of the Ethernet PG/OP channel by means of
SET_NETWORK is faulty
0xE8FC CMD - Auto command: Error: Some IP parameters missing in SET_NETWORK
0xE8FE CMD - Auto command: Error: CMD_START missing
0xE8FF CMD - Auto command: Error: Error while reading CMD file (memory card error)
0xE901 Check sum error
ZInfo1 : Not relevant to the user
ZInfo2 : Not relevant to the user
DatID : Not relevant to the user
0xE902 Internal error - Please contact the hotline!
0xEA00 Internal error - Please contact the hotline!
0xEA01 Internal error - Please contact the hotline!
0xEA02 SBUS: Internal error (internal plugged sub module not recognized)
ZInfo1 : Slot
ZInfo2 : Type ID set
ZInfo3 : Type ID
PK : Not relevant to the user
DatID : Not relevant to the user
0xEA03 SBUS: Communication error between CPU and IO controller
ZInfo1 : Slot
ZInfo2 : Status
0: OK
1: Error
2: Empty
3: Busy
4: Timeout
5: Internal blocking
6: Too many frames
7: Not connected
8: Unknown
PK : Not relevant to the user
DatID : Not relevant to the user
OB : Operation mode
0: Configuration in operation mode RUN
1: STOP (update)
2: STOP (overall reset)
3: STOP (own initialization)
4: STOP (internal)
5: Start-up (cold start)
VIPA System 300S Deployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 103
