Event ID Description
6: Start-up (cold restart/warm start)
7: Start-up (restart)
8: RUN
9: RUN (redundant operation)
10: HALT
11: COUPLING
12: UPDATING
13: DEFECTIVE
14: Troubleshooting
15: Without power
0xFD: Process image enabled in STOP
0xFE: Watchdog
0xFF: Not set
0xEA04 SBUS: Multiple configuration of a periphery address
ZInfo1 : Periphery address
ZInfo2 : Slot
ZInfo3 : Data width
0xEA05 Internal error - Please contact the hotline!
0xEA07 Internal error - Please contact the hotline!
0xEA08 SBUS: Parametrized input data width unequal to plugged input data width
ZInfo1 : Parametrized input data width
ZInfo2 : Slot
ZInfo3 : Input data width of the plugged module
0xEA09 SBUS: Parametrized output data width unequal to plugged output data width
ZInfo1 : Parametrized output data width
ZInfo2 : Slot
ZInfo3 : Output data width of the plugged module
0xEA10 SBUS: Input periphery address outside the periphery area
ZInfo1 : Periphery address
ZInfo2 : Slot
ZInfo3 : Data width
0xEA11 SBUS: Output periphery address outside the periphery area
ZInfo1 : Periphery address
ZInfo2 : Slot
ZInfo3 : Data width
0xEA12 SBUS: Error at writing record set
ZInfo1 : Slot
ZInfo2 : Record set number
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 104
