Event ID Description
ZInfo3 : Record set length
0xEA14 SBUS: Multiple parametrization of a periphery address (diagnostics address)
ZInfo1 : Periphery address
ZInfo2 : Slot
ZInfo3 : Data width
0xEA15 Internal error - Please contact the hotline!
0xEA18 SBUS: Error at mapping of the master periphery
ZInfo2 : Slot of the master
0xEA19 Internal error - Please contact the hotline!
0xEA1A SBUS: Error at access to the FPGA address table
ZInfo2 : HW slot
ZInfo3 : Table
0: Reading
1: Writing
PK : Not relevant to the user
DatID : Not relevant to the user
0xEA20 Error - RS485 interface is not pre-set to PROFIBUS DP master bus a PROFIBUS DP master is
configured
0xEA21 Error - Configuration RS485 interface X2/X3: PROFIBUS DP master is configured but missing.
ZInfo2 : Interface X is faulty configured.
0xEA22 Error - RS485 interface X2 - Value exceeds the limits
ZInfo2 : Project engineering for X2
0xEA23 Error - RS485 interface X3 - Value exceeds the limits
ZInfo2 : Project engineering for X3
0xEA24 Error - Configuration RS485 interface X2/X3: Interface/protocol missing, default settings are
used.
ZInfo2 : Project engineering for X2
ZInfo3 : Project engineering for X3
0xEA30 Internal error - Please contact the hotline!
0xEA40 Internal error - Please contact the hotline!
0xEA41 Internal error - Please contact the hotline!
0xEA50 PROFINET IO controller: Error in the configuration
ZInfo1 : Rack/slot of the controller
ZInfo2 : Device no.
ZInfo3 : Slot at the device
OB : Not relevant to the user
PK : Not relevant to the user
DatID : Not relevant to the user
0xEA51 PROFINET IO CONTROLLER: There is no PROFINET IO controller at the configured slot
VIPA System 300S Deployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 105
