Event ID Description
ZInfo1 : Diagnostics address of the master
ZInfo2 : Current connection mode
0x01: 10Mbit half-duplex
0x02: 10Mbit full-duplex
0x03: 100Mbit half-duplex
0x04: 100Mbit full-duplex
0x05: Link mode undefined
0x06: Auto Negotiation
OB : Current operation mode
0: Configuration in operation mode RUN
1: STOP (update)
2: STOP (overall reset)
3: STOP (own initialization)
4: STOP (internal)
5: Start-up (cold start)
6: Start-up (cold restart/warm start)
7: Start-up (restart)
8: RUN
9: RUN (redundant operation)
10: HALT
11: COUPLING
12: UPDATING
13: DEFECTIVE
14: Troubleshooting
15: Without power
0xFD: Process image enabled in STOP
0xFE: Watchdog
0xFF: Not set
0xEAC0 Internal error - Please contact the hotline!
0xEAD0 Error in configuration SyncUnit
0xEB02 SLIO bus: Present configuration does not match the actual configuration
ZInfo1 : Bit mask slots 1-16
ZInfo2 : Bit mask slots 17-32
ZInfo3 : Bit mask slots 33-48
DatID : Bit mask slots 49-64
0xEB03 SLIO error: IO mapping
ZInfo1 : Type of error
0x01: SDB parser error
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 112
