Event ID Description
0x02: Configured address already used
0x03: Mapping error
PK : Not relevant to the user
DatID : Not relevant to the user
ZInfo2 : Slot (0=not be determined)
0xEB05 SLIO error: Bus structure for Isochron process image not suitable
PK : Not relevant to the user
DatID : Not relevant to the user
ZInfo2 : Slot (0=not be determined)
0xEB10 SLIO error: Bus error
ZInfo1 : Type of error
0x60: Bus enumeration error
0x80: General error
0x81: Queue execution error
0x82: Error interrupt
PK : Not relevant to the user
DatID : Not relevant to the user
0xEB11 SLIO error during bus initialization
PK : Not relevant to the user
DatID : Not relevant to the user
0xEB20 SLIO error: Interrupt information undefined
0xEB21 SLIO error: Accessing configuration data
ZInfo2 : Not relevant to the user
ZInfo3 : Not relevant to the user
DatID : Not relevant to the user
0xEC03 EtherCAT: Error in configuration
ZInfo1 : Error code
1: Number of slaves is not supported.
2: Master system ID not valid
3: Slot not valid
4: Master configuration not valid
5: Master type not valid
6: Slave diagnostic address invalid
7: Slave address not valid
8: Slave module IO configuration invalid.
9: Logical address already in use.
10: Internal error
11: IO mapping error
VIPA System 300S Deployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 113
