Event ID Description
0x04: SafeOp
0x08: Op
ZInfo1 : New status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo2 : Diagnostics address of the master
ZInfo3 : Number of stations, which are not in the same state as the master
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xEC12 EtherCAT: Restoration slave
ZInfo1 : Old status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo1 : New status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo2 : Diagnostics address of the station
ZInfo3 : AL Statuscode
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xEC30 EtherCAT: Topology OK
ZInfo2 : Diagnostics address of the master
