Event ID Description
0: Configuration in operation mode RUN
1: STOP (update)
2: STOP (overall reset)
3: STOP (own initialization)
4: STOP (internal)
5: Start-up (cold start)
6: Start-up (cold restart/warm start)
7: Start-up (restart)
8: RUN
9: RUN (redundant operation)
10: HALT
11: COUPLING
12: UPDATING
13: DEFECTIVE
14: Troubleshooting
15: Without power
0xFD: Process image enabled in STOP
0xFE: Watchdog
0xFF: Not set
ZInfo1 : New status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo2 : Slave address
ZInfo3 : AlStatusCode
0x0000: No Error
0x0001: Unspecified error
0x0011: Invalid requested status change
0x0012: Unknown requested status
0x0013: Bootstrap not supported
0x0014: No valid firmware
0x0015: Invalid mailbox configuration
0x0016: Invalid mailbox configuration
0x0017: Invalid sync manager configuration
0x0018: No valid inputs available
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
