n In opposite to the "standard" backplane bus where the modules
are plugged-in at the right side of the CPU by means of single bus
connectors, the modules at the SPEED-Bus are plugged-in at the
left side of the CPU via a special SPEED-Bus rail.
n VIP
A delivers profile rails with integrated SPEED-Bus for 2, 6, or
10 SPEED-Bus peripheral modules with different lengths.
Each SPEED-Bus rail has a slot for an external power
supply
. The deployment of this external power supply
at the CPU 314-6CF03 is not permitted.
The CPU has a PROFIBUS/PtP interface with a fix pinout. After an
overall reset the interface is deactivated. By appropriate configura-
tion, the following functions for this interface may be enabled:
n PROFIBUS DP master operation: Configuration via PROFIBUS
sub module with ‘Operation mode’ master in the hardware config-
uration.
n PROFIBUS DP slave operation: Configuration via PROFIBUS sub
module with ‘Operation mode’ slave in the hardware configura-
tion.
n PtP functionality: Configuration as virtual PROFIBUS master
system by including the VIP
A SPEEDBUS.GSD.
The CPU has an Ethernet interface for PG/OP communication. After
assigning IP address parameters with your configuration tool, via the
"PLC" functions you may directly access the Ethernet PG/OP channel
and program res. remote control your CPU. Y
ou may also access the
CPU with a visualization software via these connections.
n Wiring by means of spring pressure connections (CageClamps) at
the front connector
n Core cross-section 0.08...2.5mm
2
n T
otal isolation of the wiring at module change
n Potential separation of all modules to the backplane bus
Dimensions of the basic enclosure:
n 2tier width: (WxHxD) in mm: 80x125x120
The CPU comes with an integrated power supply. The power supply
is to be supplied with DC 24V
. By means of the supply voltage, the
internal electronic is supplied as well as the connected modules via
backplane bus. The power supply is protected against inverse polarity
and overcurrent.
Integrated PROFIBUS
DP master/slave respec-
tively PtP functionality
Integrated Ethernet
PG/OP
channel
Operation Security
Dimensions/ Weight
Integrated power supply
VIPA System 300S Basics
CPU 314-6CF03
HB140 | CPU | 314-6CF03 | GB | 16-43 15
