Byte Record set Description
4 9Ah C0: Count value that is transferred to counter by setting bit 5 in the output status
word
4 9Bh C1: Count value that is transferred to counter by setting bit 5 in the output status
word
4 9Ch C2: Count value that is transferred to counter by setting bit 5 in the output status
word
4 9Dh C3: Count value that is transferred to counter by setting bit 5 in the output status
word
2 9Eh Activate respectively de-activate analog/digital part
Except of the parameter in record set 0, you may transfer the other
parameters during runtime by using the SFC 55, 56, 57 and 58 to the
digital part. For this you have to transfer the wanted parameters via
record set to the counter by using the according SFC in the user
application.
Byte Bit 7...0
0...3 Counter mode C0
4...7 Counter mode C1
8...11 Counter mode C2
12...15 Counter mode C3
n V
ia the record set 0 you may preset a counter mode for every
counter as double word.
n Record set 0 may not be transferred during runtime.
Record set 0 -
Counter mode
VIPA System 300S Deployment I/O periphery
Counter - Parametrization
HB140 | CPU | 314-6CF03 | GB | 16-43 153
