Byte Bit 15...0
8...9
n Input filter I+0.4 in 2.56ms
10...11
n Input filter I+0.5 in 2.56ms
12...13
n Input filter I+0.6 in 2.56ms
14...15
n Input filter I+0.7 in 2.56ms
16...17
n Input filter I+1.0 in 2.56ms
18...19
n Input filter I+1.1 in 2.56ms
20...21
n Input filter I+1.2 in 2.56ms
22...23
n Input filter I+1.3 in 2.56ms
24...25
n Input filter I+1.4 in 2.56ms
26...27
n Input filter I+1.5 in 2.56ms
28...29
n Input filter I+1.6 in 2.56ms
30...31
n Input filter I+1.7 in 2.56ms
n This record set allows you to preset an input filter in steps of
2.56ms steps for I+0.0 ... I+1.7.
n By preceding a filter you define how long an input signal must be
present before it is recognized as "1" signal. With the help of filters
you may e.g. filter signal peaks at a blurred input signal.
n The entry happens as a factor of 2.56
μs and is within the range
1 ... 16000 i.e. 2.56ms ... 40.96ms.
Counter 0
87h
Counter 1
8Dh
Counter 2
93h
Counter 3
99h
Type Function
82h 88h 8Eh 94h Double word comparison value
83h 89h 8Fh 95h Double word Load value
84h 8Ah 90h 96h Double word End value
85h 8Bh 91h 97h Word Hysteresis
86h 8Ch 92h 98h Word Pulse
n Each of the counter parameters has an assigned record set
depending on the counter number
.
n Additionally for every counter the parameter are summoned in one
record set.
n For every counter the record sets have the same structure.
Record set 82 ... 99h -
Counter parameter
VIPA System 300S Deployment I/O periphery
Counter - Parametrization
HB140 | CPU | 314-6CF03 | GB | 16-43 157
