Byte Bit 7...0
5 Number of diagnostic bits per channel (here 08h)
6 Number of channels of a module (here 08h)
7
n Bit 0: Error in channel group 0 (I+0.0 ... I+0.3)
n Bit 1: Error in channel group 1 (I+0.4 ... I+0.7
n Bit 2: Error in channel group 2 (I+1.0 ... I+1.3)
n Bit 3: Error in channel group 3 (I+1.4 ... I+1.7)
n Bit 4: Error in channel group 4 (counter 0)
n Bit 5: Error in channel group 5 (counter 1)
n Bit 6: Error in channel group 6 (counter 2)
n Bit 7: Error in channel group 7 (counter 3)
8 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... input I+0.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.2
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.3
n Bit 7: 0 (fix)
9 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... input I+0.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.7
n Bit 7: 0 (fix)
10 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... input I+1.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.2
n Bit 5: 0 (fix)
n Bit 6: ... Input I+1.3
n Bit 7: 0 (fix)
VIPA System 300S Deployment I/O periphery
Counter - Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU | 314-6CF03 | GB | 16-43 175
