Byte Bit 7...0
11 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... input I+1.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.7
n Bit 7: 0 (fix)
12 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... gate counter 0 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 0 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value Counter 0
n Bit 5: 0 (fix)
n Bit 6: ... counter 0 reached comparison value
n Bit 7: 0 (fix)
13 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... gate counter 1 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 1 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value Counter 1
n Bit 5: 0 (fix)
n Bit 6: ... counter 1 reached comparison value
n Bit 7: 0 (fix)
VIPA System 300SDeployment I/O periphery
Counter - Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU | 314-6CF03 | GB | 16-43 176
