Byte Bit 7...0
14 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... gate counter 2 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 2 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value Counter 2
n Bit 5: 0 (fix)
n Bit 6: ... counter 2 reached comparison value
n Bit 7: 0 (fix)
15 Diagnostic interrupt due to process interrupt lost at...
n Bit 0: ... gate counter 3 closed
n Bit 1: 0 (fix)
n Bit 2: ... gate counter 3 opened
n Bit 3: 0 (fix)
n Bit 4: ... over-/underflow/end value Counter 3
n Bit 5: 0 (fix)
n Bit 6: ... counter 3 reached comparison value
n Bit 7: 0 (fix)
VIPA System 300S Deployment I/O periphery
Counter - Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU | 314-6CF03 | GB | 16-43 177
