For transfer via Ethernet the CPU has the following interface:
n X5: Ethernet PG/OP channel
So that you may the according Ethernet interface, you have to assign
IP address parameters by means of the "initialization".
Please consider to use the same IP address data in your project for
the CP 343-1.
1. For the transfer
, connect, if not already done, the appropriate
Ethernet jack to your Ethernet.
2. Open your project with the Siemens TIA Portal.
3. Click in the Project tree at Online access and choose here by a
double-click your network card, which is connected to the
Ethernet PG/OP interface.
4. Select in the Project tree your CPU and click at [Go online].
5. Set the access path by selecting "PN/IE" as type of interface,
your network card and the according subnet. Then a net scan is
established and the corresponding station is listed.
6. Establish with [Connect] a connection.
7.
Click to ‘Online è Download to device
’.
ð
The according block is compiled and by a request trans-
ferred to the target device. Provided that no new hardware
configuration is transferred to the CPU, the entered Ethernet
connection is permanently stored in the project as transfer
channel.
The memory card serves as external storage medium. There may be
stored several projects and sub-directories on a memory card. Please
regard that your current project is stored in the root directory and has
one of the following file names:
n S7PROG.WLD
n AUT
OLOAD.WLD
1. Create in the Siemens TIA Portal a wld file with ‘Project
è Memory card file è New
’.
ð
The wld file is shown in the Project tree at "SIMATIC Card
Reader" as "Memory card file".
2. Copy the blocks from the Program blocks to the wld file. Here
the hardware configuration data are automatically copied to the
wld file as "System data".
The transfer of the application program from the memory card into the
CPU takes place depending on the file name after an overall reset or
PowerON.
n S7PROG.WLD is read from the memory card after overall reset.
n AUT
OLOAD.WLD is read from the memory card after PowerON.
Transfer via Ethernet
Initialization
Transfer
Transfer via memory
card
Transfer memory card
®
CPU
VIPA System 300S Configuration with TIA Portal
TIA Portal - Project transfer
HB140 | CPU | 314-6CF03 | GB | 16-43 227
