The blinking of the MC LED of the CPU marks the active transfer.
Please regard that your user memory serves for enough space for
your user program, otherwise your user program is not completely
loaded and the SF LED gets on.
When a memory card has been installed, the write command stores
the content of the RAM as S7PROG.WLD on the memory card. The
write command can be found in the Siemens TIA Portal in the T
ask
card "Online tools" in the command area at "Memory" as button [Copy
RAM to ROM]. The MC LED blinks during the write access. When the
LED expires, the write process is finished. If this project is to be
loaded automatically from the memory card with PowerON, you have
to rename this to on the memory card to AUTOLOAD.WLD.
Please note that in the Siemens TIA Portal with some
CPU types the [Copy RAM to ROM] button is not avail-
able. Instead please use the CMD auto command
SA
VE PROJECT.
Ä
Chapter 5.19 ‘CMD - auto com-
mands’ on page 92
After accessing the memory card you can find a diagnostics entry in
the CPU. To monitor the diagnostics entries, you select Online &
Diagnostics in the Siemens TIA Portal. Here you can access the
"Diagnostics buffer".
Ä
Chapter 5.20 ‘Diagnostic entries’ on page 94
Transfer CPU
®
Memory card
Checking the transfer
operation
VIPA System 300SConfiguration with TIA Portal
TIA Portal - Project transfer
HB140 | CPU | 314-6CF03 | GB | 16-43 228
