Order no. 314-6CF03
Power loss 14 W
Technical data digital inputs
Number of inputs 8
Cable length, shielded 1000 m
Cable length, unshielded 600 m
Rated load voltage DC 24 V
Reverse polarity protection of rated load
voltage
ü
Current consumption from load voltage L+
(without load)
70 mA
Rated value DC 24 V
Input voltage for signal "0" DC 0...5 V
Input voltage for signal "1" DC 15...28.8 V
Input voltage hysteresis -
Frequency range -
Input resistance -
Input current for signal "1" 6 mA
Connection of Two-Wire-BEROs possible
ü
Max. permissible BERO quiescent current 1.5 mA
Input delay of "0" to "1" parameterizable 2.56µs - 40ms
Input delay of "1" to "0" parameterizable 2.56µs - 40ms
Number of simultaneously utilizable inputs hori-
zontal configuration
8
Number of simultaneously utilizable inputs ver-
tical configuration
8
Input characteristic curve IEC 61131-2, type 1
Initial data size 34 Byte
Technical data digital outputs
Number of outputs 8
Cable length, shielded 1000 m
Cable length, unshielded 600 m
Rated load voltage DC 24 V
Reverse polarity protection of rated load
voltage
-
Current consumption from load voltage L+
(without load)
30 mA
VIPA System 300SHardware description
Technical data
HB140 | CPU | 314-6CF03 | GB | 16-43 42
