Order no. 314-6CF03
Total current per group, horizontal configura-
tion, 40°C
4 A
Total current per group, horizontal configura-
tion, 60°C
3 A
Total current per group, vertical configuration 3 A
Output voltage signal "1" at min. current L+ (-0.8 V)
Output voltage signal "1" at max. current L+ (-0.8 V)
Output current at signal "1", rated value 0.5 A
Output current, permitted range to 40°C 5 mA to 0.6 A
Output current, permitted range to 60°C 5 mA to 0.6 A
Output current at signal "0" max. (residual cur-
rent)
100 µA
Output delay of "0" to "1" 100 µs
Output delay of "1" to "0" 100 µs
Minimum load current -
Lamp load 5 W
Parallel switching of outputs for redundant con-
trol of a load
possible
Parallel switching of outputs for increased
power
not possible
Actuation of digital input
ü
Switching frequency with resistive load max. 2.5 kHz
Switching frequency with inductive load max. 0.5 Hz
Switching frequency on lamp load max. 2.5 kHz
Internal limitation of inductive shut-off voltage L+ (-52 V)
Short-circuit protection of output yes, electronic
Trigger level 1 A
Number of operating cycle of relay outputs -
Switching capacity of contacts -
Output data size 18 Byte
Technical data analog inputs
Number of inputs 5
Cable length, shielded 200 m
Rated load voltage DC 24 V
Reverse polarity protection of rated load
voltage
ü
VIPA System 300S Hardware description
Technical data
HB140 | CPU | 314-6CF03 | GB | 16-43 43
