Order no. 314-6CF03
Current consumption from load voltage L+
(without load)
85 mA
Voltage inputs
ü
Min. input resistance (voltage range) 120 kΩ
Input voltage ranges -10 V ... +10 V
0 V ... +10 V
Operational limit of voltage ranges +/-0.3%
Operational limit of voltage ranges with SFU -
Basic error limit voltage ranges +/-0.3%
Basic error limit voltage ranges with SFU -
Destruction limit voltage max. 15V
Current inputs
ü
Max. input resistance (current range) 85 Ω
Input current ranges -20 mA ... +20 mA
0 mA ... +20 mA
+4 mA ... +20 mA
Operational limit of current ranges +/-0.3%
Operational limit of current ranges with SFU -
Basic error limit current ranges +/-0.2%
Radical error limit current ranges with SFU -
Destruction limit current inputs (electrical cur-
rent)
max. 50mA
Destruction limit current inputs (voltage) max. 15V
Resistance inputs
ü
Resistance ranges 0 ... 600 Ohm
Operational limit of resistor ranges +/-0.4%
Operational limit of resistor ranges with SFU -
Basic error limit +/-0.2%
Basic error limit with SFU -
Destruction limit resistance inputs max. 15V
Resistance thermometer inputs
ü
Resistance thermometer ranges Pt100
Pt1000
Ni100
Ni1000
VIPA System 300SHardware description
Technical data
HB140 | CPU | 314-6CF03 | GB | 16-43 44
