Order no. 314-6CF03
Between channels and power supply -
Max. potential difference between circuits DC 75 V/ AC 50 V
Max. potential difference between inputs (Ucm) -
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and
Mana (Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
-
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Command processing times
Bit instructions, min. 0.01 µs
Word instruction, min. 0.01 µs
Double integer arithmetic, min. 0.01 µs
Floating-point arithmetic, min. 0.06 µs
Timers/Counters and their retentive charac-
teristics
Number of S7 counters 512
S7 counter remanence 0 .. 512
S7 counter remanence adjustable C0 .. C7
Number of S7 times 512
S7 times remanence 0 .. 512
S7 times remanence adjustable not retentive
Data range and retentive characteristic
Number of flags 8192 Byte
Bit memories retentive characteristic adjustable 0 .. 8192
Bit memories retentive characteristic preset MB0 .. MB15
Number of data blocks 4095
Max. data blocks size 64 KB
Max. local data size per execution level 1024 Byte
Blocks
Number of OBs 23
Number of FBs 2048
Number of FCs 2048
