Order no. 314-6CF03
S7 basic communication, user data per job 76 Byte
S7 communication
ü
S7 communication as server
ü
S7 communication as client -
S7 communication, user data per job 160 Byte
Number of connections, max. 32
PWM data
PWM channels -
PWM time basis -
Period length -
Minimum pulse width -
Type of output -
Functionality Sub-D interfaces
Type X2
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated
ü
MPI
ü
MP²I (MPI/RS232) -
DP master -
DP slave -
Point-to-point interface -
5V DC Power supply max. 90mA, isolated
24V DC Power supply max. 100mA, non-isolated
Type X3
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated
ü
MPI -
MP²I (MPI/RS232) -
DP master yes
DP slave yes
Point-to-point interface
ü
VIPA System 300SHardware description
Technical data
HB140 | CPU | 314-6CF03 | GB | 16-43 50
