Event ID Description
0x05: Status interrupt
0x06: Update interrupt
0x07: Redundancy interrupt
0x08: Controlled by the supervisor
0x09: Enabled
0x0A: Wrong sub module plugged
0x0B: Restoration of the sub module
0x0C: Diagnostic interrupt (outgoing)
0x0D: Cross traffic connection message
0x0E: Neighbourhood change message
0x0F: Synchronisation message (bus)
0x10: Synchronisation message (device)
0x11: Network component message
0x12: Clock synchronisation message (bus)
0x1F: Pull interrupt module
ZInfo3: CoE error code
0xE003 Error on accessing the periphery
ZInfo1 : Transfer type
ZInfo2 : Periphery address
ZInfo3 : Slot
0xE004 Multiple configuration of a periphery address
ZInfo1 : Periphery address
ZInfo2 : Slot
0xE005 Internal error - Please contact the hotline!
0xE007 Configured in-/output bytes do not fit into periphery area
0xE008 Internal error - Please contact the hotline!
0xE009 Error on accessing the standard backplane bus
0xE010 There is a undefined module at the backplane bus
ZInfo2 : Slot
ZInfo3 : Type ID
0xE011 Master project engineering at slave CPU not possible or wrong slave configuration
0xE012 Error at parametrization
0xE013 Error at shift register access to standard bus digital modules
0xE014 Error at Check_Sys
0xE015 Error at access to the master
ZInfo2 : Slot of the master
ZInfo2 : Page frame master
0xE016 Maximum block size at master transfer exceeded
VIPA System 300S Deployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 95
