Event ID Description
11: Wrong sequence number
12: Faulty block number in the telegram
13: Faulty block type in the telegram
14: Inactive function
15: Wrong size in the telegram
20: Error in writing on MMC
90: Faulty buffer size
98: Unknown error
99: Internal error
0xE0CD Error at DP-V1 job management
ZInfo1 : Not relevant to the user
ZInfo2 : Not relevant to the user
ZInfo3 : Not relevant to the user
DatID : Not relevant to the user
0xE0CE Error: Timeout at sending of the i-slave diagnostics
0xE100 Memory card access error
0xE101 Memory card error file system
0xE102 Memory card error FAT
0xE104 Memory card error at saving
ZInfo3 : Not relevant to the user
0xE200 Memory card writing finished (Copy Ram2Rom)
PK : Not relevant to the user
OB : Not relevant to the user
0xE210 Memory card reading finished (reload after overall reset)
ZInfo1 : Not relevant to the user
PK : Not relevant to the user
OB : Not relevant to the user
0xE21E Memory card reading: Error at reload (after overall reset), error in block header
ZInfo1 : Block type
0x38: OB
0x41: DB
0x42: SDB
0x43: FC
0x44: SFC
0x45: FB
0x46: SFB
0x6F: VOB
0x65: VFB
