Vishay P3 User Manual

- 6 -
Control: Software
Values:
P- to D120: 11.9KΩ ±0.1% (5000µε at GF = 2.00)
P- to D350: 34.8KΩ ±0.1% (5000µε at GF = 2.00)
P- to D1000: 99.5KΩ ±0.1% (5000µε at GF = 2.00)
Remote calibration: Switch contacts at input terminal
block
2.13 Analog Output
Value: 0 to 2.5V max
Ranges: ±320 µε, ±3200 µε, ±32000 µε
Update rate: 480 samples/sec
Output Load: 2000Ω
Connector: BNC
2.14 Power
Battery: Two Alkaline "D" cells
Battery life: 400 hours typ.
AC Adapter: 6-15VDC 100mA
USB: 5V 100mA
2.15 Operational Environment
Temperature: 0° to +50°C
Humidity: Up to 90% RH. Non-condensing
2.16 Case
Material: Aluminum
Accessories: Two rubber grommets installed in the lid
allow leadwires to enter the case with the lid closed for
increased resistance to water splash
