Vishay P3 User Manual

- 10 -
3.4 LCD Display
The LCD display provides the visual interface to control, setup,
and monitor the P3.
3.5 Keypad
The keypad is a membrane-switch type. Functionality of the
keys is described in the Operation section.
3.6 Power Connector
The power jack accepts a 6 to 15V DC source (0.1A max).
3.7 Analog Output Connector
The analog output jack provides a 0-2.5 volt output signal that
corresponds to the displayed value. The output range is user-
selectable.
