- 8 -
3 FRONT PANEL
3.1 USB Interface
The USB interface is the communication channel between the
P3 and a host PC. All front panel controls (except the system
calibration option) are accessible via the USB interface.
USB
Interface
Memory
Card Slot
Input
Terminals
Keypad
Power
Connector
Analog
Output
Connector
LCD
Display
